Semiconductor Design Services
High-Voltage IC Design Services
NOVELIC offers high-voltage IC design services, including related layout services.
- Design and development of high-voltage, high-current switches and ultra-fast (20 ns max propagation delay) gate drivers
- Design and layout of various building blocks (IO, over temperature detection, low-side driver over-current protection, VBG modification, analog and digital supply undervoltage detection, current sensing, etc.)
- Full design and layout support from specs to GDS
- Power supply and driver module EMC testing
- SK keyfoundry BCD and X-FAB SOI design and testing
- SOIC-8 package modeling
- Testing and characterization of devices
DC-DC Buck Converter
A current-mode control, 2.1 MHz synchronous step-down DC-DC converter featuring integrated high-voltage power MOSFETs, configurable output voltage, and support for up to 1 A load current.
Applications
- Automotive battery-powered systems
- Industrial equipment
- Consumer electronics and power supplies
Key Features
- Input voltage range: 6 V – 28 V
- Output voltage range: configurable, 2.5 V to 6 V
- Output load current: up to 1 A
- Operating frequency: 2.1 MHz
- Built-in protection features and diagnostic capabilities
- Input voltage range: 6 V – 28 V
- Output voltage range: configurable, 2.5 V to 6 V
- Output load current: up to 1 A
- Operating frequency: 2.1 MHz
- Built-in protection features and diagnostic capabilities
SiC Non-Isolated Gate Driver
A single-channel, non-isolated silicon-carbide FET gate driver featuring 12 A source and sink capabilities.
Applications
- SiC-FET and IGBT traction inverters for EV/HEV
- Industrial motor drives and power supplies
- On-board chargers and EV charging stations
- Solar inverters and telecom equipment
Key Features
- Drive strength: 12 A source, 12 A sink
- Separate pull-up and pull-down gate paths
- Integrated SiC Gate On and OFF comparators
- Integrated Active Miller Clamp MOS-FET
- Integrated ADC with NTC or diode measurement
- Drive strength: 12 A source, 12 A sink
- Separate pull-up and pull-down gate paths
- Integrated SiC Gate On and OFF comparators
- Integrated Active Miller Clamp MOS-FET
- Integrated ADC with NTC or diode measurement
